AB 1746-INT4 Analog Input Module – Industrial Automation Innovation

Product Type:Analog Input Module

Manufacturer:AB (Allen-Bradley)

Model Number:1746-INT4

Number of Channels:4

Common Mode Voltage Range:-20 to 20 V

Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Max.)

Input Range:-10 to 10 VDC – 1 LSB

Absolute Input Current:-30 to 30 mA (Max.)

Voltage Rating:Overvoltage protection: 7.5 VAC RMS

Current Rating:Backplane current draw: 35 mA at 5 V, 85 mA at 24 V

Isolation:Backplane: 500 VDC, Enclosure: Open Type

Operating Temperature:-40°C to +70°C

Power Consumption:Less than 2 W

    The AB 1746-INT4 Analog Input Module is an essential component for industrial control systems, enabling the seamless integration of various sensors and actuators. It boasts four high-precision input channels capable of accepting voltage or current signals, making it suitable for a wide range of applications in manufacturing, process control, and automation environments.

    Engineered with robust materials and advanced circuitry, this module ensures accurate data acquisition even under harsh industrial conditions. Its compatibility with international safety standards guarantees reliability and compliance across different regions and industries.

    With its compact size and terminal block connector design, the 1746-INT4 facilitates easy installation and connection to existing systems without compromising on functionality. Its temperature range specification allows for operation in extreme environments, ensuring continuous performance in challenging industrial settings.

    Designed for durability and ease of maintenance, the AB 1746-INT4 Analog Input Module features a modular construction that simplifies upgrades and replacements, reducing downtime and maintenance costs. It supports a maximum power consumption of 20mA at 5VDC, providing efficient energy use without compromising performance.

    This module is a testament to Allen-Bradley’s commitment to innovation and quality, offering a versatile solution for enhancing the precision and reliability of industrial automation processes. Whether you’re looking to expand your system capabilities or improve existing infrastructure, the AB 1746-INT4 Analog Input Module is an indispensable tool for achieving operational excellence.
