AB 1756-CN2RXT – ControlNet Redundant Bridge Module for Industrial Automation

Model Type:Redundant Bridge Module

Manufacturer:Allen-Bradley

ControlNet Compatibility:A/B

Number of Channels:2

Current Rating:Drawn: 970 mA at 5.1 VDC, 1.7 mA at 24 VDC

Isolation Level:30 V (Continuous)

Enclosure Type:Open

RFI Suppression:Radiated: 10 V/M with 1 KHZ sine-wave 80% AM from 80 – 2000 MHz

Temperature Rating:Continuous operation within -40°C to +85°C

Communication Protocol:ControlNet

    Engineered for reliability and efficiency, the AB 1756-CN2RXT is designed to withstand harsh industrial environments while ensuring uninterrupted data flow between control systems and peripheral devices.

    This module supports dual redundant communication paths, enhancing system availability and reducing the risk of downtime caused by single point failures.

    Utilizing advanced isolation technology, it ensures robust electrical separation, protecting against electromagnetic interference and ensuring secure data transmission.

    With its open-type enclosure, the AB 1756-CN2RXT is suitable for various mounting scenarios, offering flexibility in integration with existing infrastructure.

    Backed by Allen-Bradley’s commitment to quality and support, this module comes with comprehensive documentation and access to extensive training resources, facilitating easy installation and maintenance.
