Brand:ABB
Model:CP430T-ETH
Order Number:1SBP260196R1001
Operating Voltage:220 V
Ethernet:Yes
Flash Memory:4 MB
RAM:16 MB
CPU:32-bit RISC
Battery-backed Memory:512 KB
Data/Recipe Storage:512 KB
Real-time Clock:Yes (with rechargeable lithium battery)
Display Type:Color TFT LCD, 64K colors, 320×240 pixels
Backlight Life:Approximately 60,000 hours at 25°C
Touchscreen:Analog
Panel Dimensions:195.0 x 145.0 x 6.0 mm (W x H x D)
Installation Depth:59.1 mm
Cutout Size:185.8 x 135.8 mm
Sealing Rating:IP65/NEMA 4X (Indoor use only)
Weight:0.86 kg
The ABB CP430T-ETH is an essential component for modern industrial control systems. Its advanced Ethernet connectivity allows seamless integration with other devices and systems, enhancing efficiency and productivity.
This control panel is equipped with a large color TFT LCD display that provides clear and detailed information. The touch screen interface is user-friendly, making it easy to navigate and operate even in challenging industrial environments.
With robust data management capabilities, including 4 MB of flash memory and 16 MB of RAM, the CP430T-ETH can store extensive amounts of operational data and recipes. This ensures smooth and consistent performance in various applications.
The real-time clock feature, powered by a rechargeable lithium battery, maintains accurate timekeeping and supports critical timing functions in automated processes. Additionally, the IP65/NEMA 4X front panel seal ensures protection against dust and water ingress, making it suitable for indoor use.
Designed with a focus on reliability and durability, the CP430T-ETH features a sturdy construction and user-friendly controls. The front panel dimensions are 195.0 x 145.0 x 6.0 mm, and it can be installed with a depth of 59.1 mm, making it a versatile solution for industrial settings.
