Allen-Bradley 1769-OW8I CompactLogix Relay Output Module – Control and Automation Solutions

Module Type:Relay Output

Model Number:1769-OW8I

Compatible Controllers:CompactLogix and MicroLogix 1500 LRP Controllers (excluding certain models)

Ethernet Technology:Modbus TCP/IP Server and Client protocol support

Input Voltage Range:19.2-31.2VDC

Nominal Voltage:24VDC

Power Consumption:≤100VA at 24V DC

Fuse Type:Wickmann 19193-6.3A and Littelfuse 021706.3MXP

Mounting Options:Panel or DIN Rail

Dimensions:118 x 70 x 87 mm (4.65 x 2.76 x 3.43 in.)

Weight:630 g (1.39 lb)

    The Allen-Bradley 1769-OW8I is engineered for durability and reliability, making it an ideal choice for challenging industrial environments. Its compact design allows for easy integration into existing systems, enhancing efficiency without compromising on functionality.

    Featuring eight relays, this module provides versatile control capabilities, supporting a wide range of applications from simple logic operations to complex process control tasks. The 24VDC power supply ensures compatibility with a broad spectrum of industrial devices.

    With an input voltage range of 19.2-31.2VDC, the module offers exceptional flexibility, capable of operating within various power sources found in different industrial settings. This feature enables seamless deployment across multiple industries including food processing, petrochemical, pulp and paper, automobile manufacturing, and water and wastewater management.

    Designed for ease of use, the Allen-Bradley 1769-OW8I includes comprehensive documentation and support materials to facilitate quick setup and maintenance. Its compatibility with the Allen-Bradley PLC system ensures seamless integration with existing automation infrastructure, streamlining the upgrade process for users.

    Equipped with advanced diagnostics and monitoring features, the module helps in identifying potential issues promptly, minimizing downtime and maximizing operational efficiency. The inclusion of a panel or DIN rail mounting option further enhances its adaptability, allowing for flexible installation in diverse industrial setups.
