Manufacturer:General Electric
Model:DS3800HRRB1C1B
Type:RELAY OUTPUT DIG I/O Board
Compatibility:For Mark IV Speedtronic Turbine Control Systems
Number of Regulators:Approximately 70
Energy Handling Capacity:Designated by stripes on resistors
Memory Types:Mixture of 16 EEPROM and EPROMS
EPROMs:Can be encoded as needed
EEPROMs:Can only be encoded once
Ports:Two ports (marked with letters A-J)
Physical Characteristics:Seven thin barriers across the board
Mounting Options:Twelve places for screw mounting
LEDs:Over thirty-five red LEDs
The DS3800HRRB1C1B is meticulously engineered for high-performance industrial applications.
Its robust design features approximately seventy regulators, each capable of handling a specific amount of energy as indicated by external markings.
The board is equipped with a mix of sixteen EEPROM and EPROM memory types, offering flexibility and reliability in data storage and encoding.
With two ports marked from A to J, this board facilitates easy integration with various wiring harnesses.
Additionally, its compact size allows for versatile mounting options, including twelve screw mounts, ensuring secure placement within your system setup.
Featuring over thirty-five red LEDs, this board provides clear visual feedback on operational status, enhancing maintenance and troubleshooting efficiency.
