Manufacturer:General Electric
Model:SR469-P1-HI-A20-T-H
Category:Motor Management Relay
Phase Current Inputs:1 A phase CT secondaries, Primary CT rated 1 to 5000 Amps
Rated Frequency:20-70 Hz
Control Power:70-265 VAC @ 48-62 Hz, 90-300 VDC
Analog Outputs:Four (4) 4 to 20 mA analog outputs
Ports:3 (Front RS232, Rear Com RS485 and Aux RS485)
Environmental Protection:Harsh (chemical) environment conformal coating
Weight Before Packaging:Less than 15 lbs
Software:EnerVista 469 Setup
The GE SR469-P1-HI-A20-T-H Motor Management Relay is a highly reliable device designed for motor protection and control in industrial settings. This advanced relay is equipped with 1 A phase CT secondaries and a primary CT rated up to 5000 Amps, ensuring precise monitoring of current levels. With a wide frequency range of 20-70 Hz, it adapts seamlessly to various operational conditions. Its control power is robust, operating efficiently within a range of 70-265 VAC or 90-300 VDC.
The device comes with four (4) 4 to 20 mA analog outputs for versatile signal transmission, supporting a wide array of applications. It features three communication ports, including a front RS232 port and rear RS485 ports, enabling direct connection to computers and facilitating easy setpoint editing and data viewing through the EnerVista software. The unit is designed to withstand harsh environments with its conformal coating, ensuring durability in chemical settings.
Its lightweight design, weighing less than 15 lbs, makes installation straightforward, while the EnerVista 469 Setup software provides comprehensive management capabilities, enhancing operational efficiency and reducing troubleshooting time.
