General Electric DS3800HPTKIGIH – Gate Driver Module, Turbo Control Systems, Mark IV

Model Number:DS3800HPTKIGIH

Manufacturer:General Electric

Series:Mark IV Speedtronic

Application:Turbine Control Systems

Resistors:Fifteen long grey resistors, 18 Ohms ±5%, 10W rating

Color-coded Resistors:Ten additional resistors with color bands indicating their current capacity

Diodes:Thirteen various colored diodes

Capacitors:Three capacitors ranging from small to very large

Transformer:Silver square transformer with a black cover

LEDs:One small red LED

Potentiometer:Small blue potentiometer or variable resistor

Glass Fuse:Large glass fuse

    The DS3800HPTKIGIH from General Electric is a specialized gate driver board designed for Mark IV Speedtronic turbine control systems. This board plays a vital role in managing the electrical signals sent to power semiconductor devices. Equipped with a robust design featuring fifteen long grey resistors each rated for 18 Ohms ±5% and ten other color-coded resistors for varied current capacities, this board ensures high precision and stability. The board also includes thirteen diodes of different colors and three capacitors of varying sizes, enhancing its adaptability to diverse operational conditions. With a large glass fuse and a small red LED indicator, it provides clear operational status visibility. Additionally, a small blue potentiometer allows for fine-tuning of the board’s settings. The silver transformer in the center, covered by a black shield, facilitates efficient energy transfer between circuits, contributing to the overall performance of the system. This board is an indispensable part of any Mark IV turbine control setup, ensuring smooth operation and optimal performance under demanding industrial environments.
