Voltage Rating:600V
Current Capacity:50A
Switching Frequency:Up to 100kHz
Operating Temperature Range:-40°C to +125°C
Protection Features:Overcurrent, Overvoltage, Short Circuit Protection
Input Voltage:3-phase 380V – 480V AC
Output Voltage:Adjustable DC Output
Efficiency:Up to 97%
Dimensions:Width: 150mm, Height: 100mm, Depth: 50mm
Weight:2.5kg
Designed for use in industrial environments, the General Electric TS5850N60 Power Electronic Module offers unparalleled reliability and efficiency. Its robust design ensures it can withstand harsh conditions and provide consistent performance over time.
This power electronic module is built using advanced semiconductor technology, which allows for minimal power loss and maximum energy efficiency. It is perfect for a variety of applications, including motor drives, renewable energy systems, and industrial automation.
The TS5850N60 is engineered with a compact form factor, making it easy to integrate into existing systems without requiring significant modifications or additional space. Its IP65 protection rating ensures it is dust-tight and protected against water jets, making it suitable for outdoor and indoor installations alike.
Equipped with a wide operating temperature range, this module can operate efficiently in extreme temperatures, from cold environments down to -40°C up to hot ones at +125°C. This makes it an ideal choice for applications where temperature variations are common.
Installation is straightforward thanks to its intuitive design. Users can connect to the module via RS-485 interface with Modbus RTU protocol, enabling seamless integration into modern control systems.
