Manufacturer:National Instruments
Model:NI PXI-GPIB
Module Category:GPIB Interface Module
Compatibility:Compatible with PXI/PXI Express chassis
Communication Protocol:GPIB (IEEE-488.2)
Number of Channels:Up to 14 channels
Data Transfer Rate:Up to 8 Mbytes/s
Connector Type:16-pin connector
Power Requirement:3.3V to 5V DC
Operating Temperature Range:-40°C to +85°C
The PXI-GPIB controller module from National Instruments is designed for integration into PXI systems to facilitate efficient and high-speed data communication using the GPIB standard. This module offers a robust solution for a variety of measurement and control applications.
It supports up to 2 Mbytes/s data transfer rates, ensuring rapid and reliable data exchange between devices. Its compact 4-slot PXI form factor makes it ideal for space-constrained environments.
This module operates within a wide temperature range of -20°C to +70°C, making it suitable for both indoor and outdoor use. It complies with the IEEE 488.2 standard, ensuring compatibility with a broad array of instruments and systems.
The controller’s design includes features like overcurrent protection and short-circuit protection to safeguard connected devices from damage due to electrical faults.
Ease of installation and configuration is a key highlight, thanks to its user-friendly interface and comprehensive documentation. Whether you’re an experienced engineer or a novice user, this module is designed to be simple to set up and operate.
