Product Type:HMI Integrated Controller
Product ID:XBTGT6330
Display Resolution:320×240 pixels
Display Size:5.7 inches
Display Technology:TFT 65K color with LED backlight
Protection Rating:IP65 / NEMA 4X / NEMA 13
Input Outputs:[20DI (16 x digital inputs (24Vdc; Sink/Source) + 4 x digital inputs (24Vdc; 100KHz high speed counter HSC)) + 20DO (16 x digital outputs (24Vdc; Sink / Transistor; 200mA/point) + 4 x digital outputs (24Vdc; PTO (65kHz pulse train) / PWM))]
Memory:16MB Application
Operating Voltage:24Vdc
The Schneider Electric XBTGT6330 combines cutting-edge touchscreen technology with robust input and output capabilities, making it a versatile solution for industrial automation applications.
Designed with user-friendliness in mind, this controller features a 5.
7 inch TFT screen that displays up to 65K colors for a vivid and clear visual experience.
With its IP65 / NEMA 4X / NEMA 13 protection rating, the XBTGT6330 can withstand harsh environmental conditions, ensuring reliable operation in factory settings.
Its memory capacity of 16MB is dedicated to storing applications, allowing users to load complex programs and manage extensive data sets efficiently.
Whether you are implementing a new automation system or upgrading existing infrastructure, the XBTGT6330 stands out as a high-performance option.
