Frequency Range:0 Hz to 50 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary
Resolution:14-bit
Output Amplitude:±10 Vpp into 50Ω
Output Impedance:50Ω
Sampling Rate:100 MSa/s
Memory Depth:16 kPoints
Trigger Modes:External, Internal, Software
Connectivity:USB, LAN, GPIB, RS-232
The Tektronix 5B40 Arbitrary Function Generator is designed with advanced signal generation capabilities, enabling users to generate a wide range of waveforms with exceptional precision. Its high-resolution output ensures accurate signal representation, making it ideal for demanding applications where reliability and accuracy are paramount.
This device supports a broad spectrum of waveform types, including sine, square, triangle, ramp, pulse, noise, and arbitrary waveforms. Users can easily customize waveforms using the intuitive front panel controls or through software interfaces, providing unparalleled flexibility.
With a frequency range extending from 0.1 μHz to 50 MHz and an amplitude range spanning from 20 mVpp to 10 Vpp into 50 Ω, the Tektronix 5B40 is well-suited for a variety of industrial applications. The high sampling rate of 2 GSa/s and 16 kpts memory depth allow for detailed and complex waveform generation.
The robust construction and reliable performance of the Tektronix 5B40 make it a durable and dependable tool for industrial environments. The built-in arb memory ensures smooth operation and consistent waveform quality, even under demanding conditions.
For ease of use, the Tektronix 5B40 comes equipped with user-friendly navigation keys and programmable function keys, allowing for quick access to frequently used settings. The multiple language support enhances usability for international teams, ensuring seamless operation across different regions.
