Output Channels:1
Frequency Range:0.5 µHz to 20 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary
Arbitrary Waveform Length:Up to 16k Points
Resolution:1 µHz
Amplitude:20 mVpp to 10 Vpp
Vertical Resolution:14-bit
Phase Shift:±180°
DC Offset:±5 V
Bandwidth:Full bandwidth up to maximum frequency
Sampling Rate:25 MSa/s
The Tektronix AFG1022 Arbitrary Function Generator provides versatile signal generation for demanding industrial environments. Its compact design ensures it can fit easily into any workspace without compromising on performance.
With a wide range of supported waveforms, including sine, square, triangle, ramp, pulse, noise, and arbitrary waveforms, this generator is ideal for a variety of applications such as electronics testing, communications, and educational purposes.
Intuitive navigation keys and programmable function keys make it user-friendly and efficient. Default values are user-settable, offering flexibility and ease of use.
Built with reliability and durability in mind, the AFG1022 adheres to international standards such as RoHS/WEEE compliance, ensuring eco-friendliness and longevity. Its robust construction guarantees consistent performance over time.
This generator is compatible with various networking options including Ethernet (Modbus/TCP), RS-485 (Modbus/RTU, peer to peer, coordinated, PC-Link), and open networks (PROFIBUS-DP, CC-Link, DeviceNet). This makes it easy to integrate into existing systems and expand functionality.
