Woodward 8200-1301 Integrated Graphical Front Panel HMI

The Woodward 8200-1301 is an advanced integrated graphical front panel Human Machine Interface (HMI) designed specifically for use within the 505D Digital Governor Turbine Control series. This robust HMI provides an intuitive interface for monitoring and controlling turbine operations, making it an indispensable tool for industrial control systems.

Tag：8200-1301, 8200-1301 Controller, 8200-1301 Controller Motor, 8200-1301 Sensor, WOODWARD, WOODWARD Sensor

Power Supply:AC/DC (88-132 Vac or 90-150 Vdc)

Ambient Temperature Range:Suitable for operating ambient temperatures expected to exceed 50°C

Compliance:Marine/ATEX Compliance LVDC (18-32 Vdc)

Field Wiring:Stranded copper wire rated at least 75°C

The Woodward 8200-1301 offers unparalleled ease of use with its integrated graphical front panel design.

Designed for harsh industrial environments, this HMI ensures reliable operation under extreme conditions.

Featuring a color TFT display and equipped with RS-485 and Ethernet communication interfaces, it supports seamless integration into existing control systems.

Its Marine/ATEX compliance makes it ideal for offshore and explosive atmosphere applications.

The HMI requires stranded copper wire rated at least 75 °C for proper installation in environments with operating ambient temperatures expected to exceed 50 °C.

Woodward 8200-1301
